Main lug load center designed for service entrance equipment. Main lugs only. Single-phase, 3-wire, flush or surface mount. Solid neutral bar and cover included. Optional ground bar kits must be ordered separately. Load centers that accept BD and BQ type circuit breakers have a notched bus bar. UL (Underwriter's Laboratories) listed.
Features
• Designed for service entrance equipment
• Single-phase, 3-wire, flush or surface mount
• Solid neutral bar and cover included
• 125 BR series
• UL Listed
Specifications
• Amperage: 125
• Voltage: 120/240
• Series: BR
• Number of Spaces: 8
• Max Number of Poles: 16
• Enclosure Type: Indoor
• Mount Type: Surface
• Phase: Single
• Wire Size: #14 To #1
• Certification: UL Listed
• Width (In.): 11
• Height (In.): 13
• Depth (In.): 3.56
